Microscope filters

Cuihe provides fluorescence filter sets and mirror units for fluorescence microscopy and fluorescence in situ hybridization (FISH). Each set combines an excitation filter, a dichroic beam splitter and an emission filter to match the selected fluorescence channel.

Single-channel options include DAPI, Aqua, FITC, Orange and Red. Dual-band configurations are also available for FITC/TRITC and Green/Orange FISH observation. The filter set and cube housing should be selected to match the microscope, illumination source and fluorescence probe requirements.

Single-Channel FISH Filter Specifications

ChannelExcitation FilterDichroic Beam SplitterEmission Filter
DAPI (FISH-UV)BP 365/50 nmDM 405 nmBA 445/50 nm
Aqua (FISH-Blue)BP 410/20 nmDM 455 nmBA 480/30 nm
FITC (FISH-Green)BP 490/20 nmDM 505 nmBA 530/25 nm
Orange (FISH-Orange)BP 540/20 nmDM 555 nmBA 590/25 nm
Red (FISH-Red)BP 580/20 nmDM 605 nmBA 630/25 nm

All wavelengths are in nanometers (nm). BP identifies the bandpass excitation filter, DM the dichroic beam splitter, and BA the barrier (emission) filter. Bandpass notation is written as center wavelength/bandwidth; for example, 365/50 nm denotes a 365 nm center wavelength with a 50 nm bandwidth.

Dual-Band FISH Filter Options

Dual-band filter sets provide excitation and emission passbands for a pair of fluorescence channels. They should be selected according to the probe combination and the intended observation or image-acquisition workflow.

ConfigurationDichroic SpecificationExcitation and Emission Specifications
FITC/TRITC (Green/Orange)DM 490/560 nmDual-band; contact us for detailed passband specifications.
Green/Orange FISHDM 500/580 nmDual-band; contact us for detailed passband specifications.

Microscope Compatibility and Selection

Configurations for Olympus and Nikon fluorescence microscopes can be discussed by consultation. Please provide the microscope brand and model, filter-cube or mirror-unit type, illumination source, fluorescence probe names and whether you require visual observation, camera imaging or both.

Cube housing dimensions, mounting compatibility and the final optical configuration must be confirmed before ordering. Contact Cuihe for selection support, detailed specifications and a quotation.

Request FISH Filter Specifications
